Railway Locomotive Part Optional Control WG180 Hydrodynamic Transmission for Loaders

Place of Origin China
Brand Name HTR
Model Number Yb230
Minimum Order Quantity 10pcs
Price negotiable
Packaging Details Carton box, Wooden case, as per requires
Delivery Time 15-50 days, depends on QTY
Payment Terms L/C,T/T,Western Union,Paypal
Supply Ability 1,000 pcs/month

Contact me for free samples and coupons.

whatsapp:0086 18588475571

wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name WG180 Hydrodynamic Transmission Maximum Engine Speed 2600 R/Min
Gear Configurations 6 Forward / 3 Reverse, 4 Forward / 3 Reverse, 3 Forward / 3 Reverse Maximum Engine Power 190 Kw
Maximum Input Torque 1450 N·m
Leave a Message
Product Description

Products Description

1. The WG180 hydrodynamic transmission is a fixed-shaft, multi-speed hydrodynamic transmission with integrated torque converter and gearbox. It offers optional electro-hydrodynamic or mechanical-hydrodynamic control.
2. Gear configurations include 6 forward/3 reverse, 4 forward/3 reverse, or 3 forward/3 reverse.
3. It is equipped with a matching shift lever and offers optional lock-up functionality and towing pump.
4. The WG180 is widely used in engineering vehicles such as motor graders, loaders, tractors, and scrapers.


Specification

Parameters
Product Performance Reference Value
Maximum Engine Power 190 kW
Maximum Engine Speed 2600 r/min
Maximum Input Torque 1450 N·m
Gear Configurations 6 forward / 3 reverse, 4 forward / 3 reverse, 3 forward / 3
reverse
Shifting Modes Electro-hydrodynamic control, mechanical hydrodynamic control, or integrated manual-automatic
(with electro-hydrodynamic proportional control)
Input Type Torque converter can be directly connected to SAE 1#, 2#
(limited to 305 and 320 converters), or 3# (limited to 305
converter) flywheel housings, or via flange and universal joint
Output Type Flange
Optional Torque Converters 305, 320, 340, 350
Front and Rear Axle Outputs Optional rear axle disconnect mechanism available
